Ping i540 Graphite Irons
Ping i540 Graphite Irons
Couldn't load pickup availability

![]() |
![]() |
|
Maraging Steel Face |
inR-Air™ Technology |
![]() |
![]() |
|
Tungsten Weighting |
i-Beam Technology |
![]() |
![]() |
|
Player-Inspired Design |
Stock Shafts True Temper's Dynamic Gold Mid 100 promotes a mid-launch angle and spin rate with a stable feel. The PING ALTA CB Blue graphite is lightweight and counterbalanced for a mid-high to high launch. |
| Club | Length | Loft | Power Spec Loft | Lie Angle | Swingweight |
|---|---|---|---|---|---|
| 4-iron | 39 1/4 | 19.0° | 18.0° | 60.5° | D1 |
| 5-iron | 38 1/2" | 22.0° | 21.0° | 61.0° | D1 |
| 6-iron | 37 3/4" | 25.5° | 24.0° | 61.5° | D1 |
| 7-iron | 37" | 29.0° | 27.5° | 62.0° | D1 |
| 8-iron | 36 1/2" | 33.0° | 31.5° | 62.8° | D1 |
| 9-iron | 36" | 37.0° | 36.0° | 63.5° | D1.5 |
| PW | 35 1/2" | 42.0° | 41.0° | 64.1° | D2 |
| UW | 35 1/2" | 47.0° | 46.0° | 64.1° | D2 |
Notes
- These are design specifications that may vary due to manufacturing tolerances.
- Lie angle is based on standard black color code at standard length.
- Power Spec Loft is an option suitable for players seeking to increase iron distance or decrease spin to achieve their desired trajectory window.
- This custom-designed loft configuration delivers a calculated power increase without sacrificing the iron's design integrity.
- Bounce angles will vary slightly when ordered with non-standard loft specifications.
- Standard graphite shaft irons will be 2 to 3 swingweight points lighter than shown, depending on shaft flex.
- Standard Alta Distance graphite shaft irons will be 2 to 5 swingweight points lighter than shown - longer irons will be lighter.
- Achievable swingweights are dependent on shaft, length, and grip combinations.
- Available in left- and right-hand models.
SHAFTS
PING offers a variety of steel and graphite shaft flexes to meet your needs and preferences. Choosing the right shaft flex for your swing will help you maximize your distance and accuracy from every shot. In general, players with higher swing speeds need stiffer shafts to maintain a lower ball flight, while players with slower swing speeds need more flexible shafts to achieve a higher ball flight.
The choice between steel or graphite shafts is usually based on weight and/or feel preference. Players seeking a lighter overall weight and/or softer feel in their irons may prefer graphite shafts, while players who prefer a standard weight club with a firmer feel may prefer steel shafts.
We recommend seeking expert advice to find the shaft that allows you to play your best. Whether it's a softer, lighter shaft with a higher launch or a heavier, stiffer shaft with a lower trajectory, a PING Certified Club Fitter can help you find the shaft that provides greater consistency in your game.
| SHAFT | FLEX | WEIGHT | LAUNCH ANGLE |
|---|---|---|---|
|
PING Alta CB Blue
![]() |
Soft-Regular | 65.0g | High |
| Regular | 72.0g | Mid High | |
| Stiff | 82.0g | Mid | |
|
UST Recoil DART 65
![]() |
65 (A) F2 | 61.0g | Mid |
|
UST Recoil DART 75
![]() |
75 (R) F3 | 72.0g | Mid |
| 75 (R) F4 | 78.0g | Mid |
NOTES
- Shaft weights shown are based on a 7-iron cut length and may not match shaft manufacturer website specifications.
|
Golf Pride Tour Velvet 360
|
![]() |
The Golf Pride Tour Velvet represents the state of the art in rubber fusions with an anti-slip pattern that guarantees maximum playability and confidence. The surface has been specially designed to channel moisture away from the surface to always maintain a firm grip. |
